170ADI74050 - Discrete input module Modicon Momentum 16 Input 200..240 V AC - Schneider Electric

Expected in 2-4 weeks

574,32 € excl. VAT

700,67 € incl. VAT

Text About:

Discrete input module Modicon Momentum 16 Input 200..240 V AC - Schneider Electric

In cart

700,67 €

SPECIFICATIONS

Main

Group of channels 2 groups of 8 inputs

Complementary

Product certifications CSA
UL

response time 13.3 ms 60 Hz from state 0 to state 1
13.3 ms 60 Hz from state 1 to state 0

Handle front plate colour 141.5 mm

Product or component type Discrete inputs base AC

Current consumption <= 125 mA at 230 V AC

current state 0 guaranteed <= 2 mA

marking CE

current state 1 guaranteed >= 10 mA

Discrete input logic Positive

width (w) 125 mm

Input resistance 7.5 kOhm 60 Hz
9 kOhm 50 Hz

input voltage limits 164...253 V

network frequency 47...63 Hz

Discrete input voltage 230 V AC

Local signalling 16 LEDs for channel status

Discrete input number 16 conforming to IEC 1131-2 Type 2

Net weight 0.284 kg

Isolation between group 1780 V AC

Isolation between channels and bus 1780 V AC

voltage state 1 guaranteed >= 164 V

depth 47.5 mm

voltage state 0 guaranteed <= 40 V

Resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2

Terminals description plc n°1 (8)IN_DIS#8
(7)IN_DIS#7
(5)IN_DIS#5
(16)IN_DIS#16
(12)IN_DIS#12
(2)IN_DIS#2
(14)IN_DIS#14
(15)IN_DIS#15
(N)PW
(11)IN_DIS#11
(4)IN_DIS#4
(9)IN_DIS#9
(L1)PW
(3)IN_DIS#3
(6)IN_DIS#6
TB
(13)IN_DIS#13
(1)IN_DIS#1
(10)IN_DIS#10

Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3

Voltage range 163...253 V

Environment

Ambient air temp for storage/transportation -40…85 °C

operating altitude <= 5000 m

Range of product Modicon Momentum automation platform

ambient air temperature for operation 0…60 °C

relative humidity 95 % without condensation

protective treatment TC
